BRONZE PIPE
Name Norm Tensile kp/mm2 Elongation % Hardness HB Properties and Areas of Use High Tin Bronze DIN 1705 G.CuSn14 20-25 3 ... 5 85-115 Resistant to sea water,
this material is used in segment and shaft bearings and is suitable for sliding plain bearings resistant to a maximum load of 600 kp/cm2 and slides operating under pressure.
For Gears Phosphor Bronze DIN 1705 G.CuSn12 24-28 8 ... 15 80-95 Resistant to sea water and abrasion, this material is used in the production of bearings operating under low speed and heavy load in endless screw and gear arrangements.
Bearing Phosphor Bronze DIN 1705 G.CuSn10 25-28 15 ... 20 60-75 This material, resistant to abrasion, corrosion and sea water, is suitable for pump and turbine impellers, bearings operating
under heavy loads and at low rotational speeds, endless screw or worm gear arrangements as well as plain bearings. Red Bronze DIN 1705 Rg - 10 25-28 12 ... 15 65-80 Shaft bearings, flywheels, pump

It is used in the manufacture of impellers, piston rings, pump bodies, valves and parts, steam pipe fittings and gears.
Red Bronze DIN 1705 Rg - 7 22-26 12 ... 18 60-75 It is resistant to sea water and is used in the manufacture of locomotive sliding bearings, medium load operating sliding plates and slides.
Red Bronze DIN 1705 Rg - 5 20 - 24 12 ... 18 60-70 It is a cast material that can be easily hard soldered and is resistant to sea water.
It is used in the manufacture of nuts, unions and elbows used in water and steam armatures up to 225 degrees, pump bodies, electrode equipment in arc furnaces, pipe connection parts; in the manufacture of locomotive sliding bearings, water pump fans, fire equipment and equipment.
High Leaded Tin Bronze DIN 1716 G.CuPb5Sn 20 - 24 14 ... 18 70-85 It is a wear-resistant material with sliding properties. This material, which is resistant to abrasion caused by diluted sulfuric acid, chloric acid and fatty acids, is used in sliding bearings, connecting rods and hot rolling bearings subject to high surface pressure.
High Leaded TinBronzu DIN 1716 G.CuPb10Sn 18 - 23 10 ... 14 65-75 It is a medium-hard material that is resistant to abrasion and has a high sliding property; it is soft and when there is no lubrication in the bearing under difficult conditions, water can serve as lubricant. It is used in the manufacture of general maintenance bearings resistant to normal pressure and high rotation speed, rolling mill bearings, lathe bearings, electric locomotives. It is used in the casting of pumps, propellers and bodies operating in diluted acid. High Leaded Tin Bronze DIN 1716 G.CuPb20Sn 15 - 20 6 ... 10 45-55 This material is used in bearings operating at high rotation speeds under light loads. It has good sliding properties and is also resistant to acid.

It is used in the manufacture of garbage disposal machines, mill machines, water pumps and connecting rod bearings. When there is no lubrication in the bearing, water can serve as lubricant in the bearing. Aluminum Bronze DIN 1714 G.Cu Al 9 35 - 45 15 ... 25 80-110 This material, which is resistant to sea water and abrasion, is used in casting parts, chemical and food industries. Aluminum Bronze DIN 1714 G.Cu Al 10 Fe 50 - 55 13 ... 20 115-135 It is resistant to abrasion and sea water and has a wide place in the manufacture of high strength acid-resistant armatures, in shipbuilding, chemical and food industries. It is used in the manufacture of bearings, gears, endless screws, bushings, valve beds and hydraulic components. Aluminium Bronze DIN 1714 G.Cu Al 9 Ni 50 - 60 15 ... 25 120-150 This material, which is resistant to sea water, abrasion and corrosion, is used in the manufacture of propeller hubs and blades, gears, machine parts requiring durability, valve handles, lever arms and slide rails. Aluminium Bronze DIN 1714 G.Cu Al 10 Ni 60 - 65 10 ... 18 140-170 It is a material resistant to sea water, acid, cavitation and erosion. It is used in ship propellers, cylinder heads of ship diesel engines, gas and steam valves, speed pulleys and sliding bearings.

is used. Aluminum Bronze DIN 1714 G.Cu Al 11 Ni 68 - 75 5 ... 8 175-190 It is a hard material resistant to acid, sea water and abrasion. It is used in impact resistant sliding bearings, 2500 kp/cm2 load resistant lever and lever bearings, valve beds and sleeves in aircraft engines, and in the production of bushings, gears and endless gears. Aluminum Bronze DIN 1714 G.Cu Al 8 Mn 42 - 52 20 ... 26 105-120 It is a hard material resistant to sea water, corrosion and abrasion. Since it has low electrical conductivity, its permeability is poor. It is used in ships, machinery, chemical and petrochemical industries that require special alloys. It is used in the manufacture of ship propellers, turbine blades, armatures and gears. Manganese Bronze DIN 1709 G.Cu55ZnMn 30 - 35 15 ... 25 75-85 It is an easy-to-cast material that can be soldered and soldered softly. It is used in the manufacture of armatures and pump bodies that require resistance to high water and gas pressure. Manganese Bronze DIN 1709 G.Cu55ZnAl1 45 - 55 20 ... 25 105-130 This material, formerly known as bronze steel, is resistant to sea water; due to its high hardness and elasticity, it is used in the manufacture of sliding bearings, in the manufacture of screw nuts obtained by rolling and in the casting of propellers. Manganese Bronze DIN 1709

G.Cu55ZnAl2 60 - 65 15 ... 20 140-160 It is resistant to sea water and is a high hardness material. Although it is used less in casting parts requiring dynamic loads, it is used in the casting of valve and rudder parts, gear manufacturing, bushing and bearing castings and in the manufacture of parts for the shipbuilding industry. Manganese Bronze DIN 1709 G.Cu55ZnAl4 75 - 80 6 ... 10 190-220 It is suitable for the manufacture of gears, keys, bearings, bridge bearings, hydraulic cylinder parts and high pressure resistant armatures operating at low speeds and under heavy loads. It is resistant to sea water and is a very hard material.
